2835 0.5W SMD LED

2835 0.5W SMD LED for High Lumen Lighting and Backlight Projects

Name: 2835 0.5W SMD LED
Brand: KINGBRIGHT

KINGBRIGHT 2835 0.5W SMD LED, code 9.2835W3V21G-J03, is a high-efficiency surface mount LED with IF=150mA drive current, designed for traditional lighting replacement, ordinary lighting, sign board backlight and architectural decorative lighting.

Code: 9.2835W3V21G-J03Power: 0.5W / 500mWIF: 150mAVF: 2.8-3.4VCCT: 2700K-6500KCRI: Ra70 / Ra80 / Ra90

Request 0.5W 2835 Quotation Request 0.5W Samples Get 0.5W Datasheet Contact Sales Engineer Compare 2835 0.2W Review 3030 SMD LED Review 3535 3W LED

Engineering Review

KINGBRIGHT 2835 SMD LED product image for overseas B2B buyer review

2835 LED Package + Engineering Support

Small package, high efficiency, low-voltage operation, instant light response, long operation life, lead-free and RoHS compliant.

Product Images

2835 SMD LED Photos, Package Views and Application Context

2835 SMD LED Product Appearance

Real 2835 SMD LED package photo for product appearance review.

KINGBRIGHT 2835 SMD LED package dimensions and soldering pattern drawing

2835 Package Dimensions

Dimension drawing and recommended soldering pattern for engineering review.

2835 SMD LED application image for road lighting and outdoor lighting projects

Lighting Application Reference

Outdoor lighting application reference for 2835 SMD LED component selection.

Technical Specifications

Real 2835 0.5W SMD LED Datasheet Parameters

These values are taken from the KINGBRIGHT 2835 0.5W LED specification for mass production supply at TA=25 C. Flux and color values should be confirmed by selected CCT, CRI and bin requirements.

KINGBRIGHT 2835 SMD LED technical package dimensions and soldering pattern drawing — 2835 SMD LED package dimensions and recommended soldering pattern for engineering review.

Product Code9.2835W3V21G-J03

Code Structure9.2835XXV21XB-HC4-CY series, 2835 package, 3V class, 1 chip, Ra70/Ra80/Ra90 options

Package Size2.8 x 3.5 x 0.70 mm, tolerance +/-0.15 mm unless otherwise noted

Forward Voltage2.8V min / 3.4V max at IF=150mA

Forward Current150mA rated forward current

Pulse Forward Current180mA max, 10kHz frequency, duty ratio <=10%

Power Dissipation500mW / 0.5W

Color Temperature2700K / 3000K / 3500K / 4000K / 4500K / 5000K / 5700K / 6500K

Viewing Angle120 degrees at IF=150mA

Luminous Flux55-85 lm range by CCT and CRI bin at IF=150mA

CRIRa70 / Ra80 / Ra90 options

Color ToleranceSDCM <=6 at IF=150mA

Reverse Current10 uA max at VR=-5V

ESDHBM 2000V

Operating Temperature-40 C to +85 C

Storage Temperature-40 C to +85 C

Junction Temperature125 C max

Thermal Resistance46 C/W

Reverse Voltage5V

Soldering Temperature260 C for 10 sec

PackagingTape and reel packaging; label includes part number, lot number, IV, VF/IF, CCT/XY, Ra/SD/R9, quantity, date and code

Dimensions

2835 Package and Optical Package Reference

The 2835 product family includes standard flat package and ballhead package options. Final dimensions, solder pad information and recommended PCB layout should be confirmed from the official datasheet before PCB design.

KINGBRIGHT 2835 SMD LED dimension drawing with package outline polarity and solder pad pattern — Package outline, polarity reference and soldering pattern. Request the official datasheet before PCB layout confirmation.

Mass Production Bins

CCT, CRI and Luminous Flux Options at IF=150mA

CCT OptionCRILuminous Flux

6500K / 5700K / 5000KRa7080-85 lm

6500K / 5700K / 5000KRa8075-80 lm

6500K / 5700K / 5000KRa9065-70 lm

4000KRa7080-85 lm

4000KRa8075-80 lm

4000KRa9065-70 lm

3500K / 3000KRa7075-80 lm

3500K / 3000KRa8070-75 lm

3500K / 3000KRa9060-65 lm

2700KRa7070-75 lm

2700KRa8065-70 lm

2700KRa9055-60 lm

Features & Advantages

Built for Stable Brightness and Mass Production Consistency

Stable Brightness

Mass production bins support consistent luminous flux and color performance.

Low Light Decay

Silicone encapsulation and process control support reliable long-term operation.

High Efficiency

0.5W 2835 package delivers up to 80-85 lm depending on CCT and CRI bin.

Long Lifespan

Designed for operation under rated current, temperature and soldering conditions.

Good Consistency

VF, XY, brightness and Ra bin control helps reduce color and brightness variation.

Applications

Recommended for Lighting Replacement and Backlight Projects

The datasheet recommends this 2835 SMD LED for traditional lighting replacement, ordinary lighting, indoor and outdoor sign board backlight, architectural lighting and decorative lighting.

2835 SMD LED application for outdoor sports field and area lighting — Area Lighting

2835 SMD LED application for high bay industrial lighting fixture — High Bay Lighting

2835 SMD LED application for road lighting and street lighting projects — Road Lighting

Traditional lighting replacement Ordinary indoor lighting Indoor and outdoor sign board backlight Architectural lighting Decorative lighting

Datasheet Download

Request the Official 2835 0.5W SMD LED Datasheet

The datasheet includes package dimensions, coding rules, electro-optical characteristics, absolute maximum ratings, mass production list, CIE binning, packaging specifications, reflow soldering instructions and handling precautions.

Get Official Datasheet

Packaging & Reflow

Tape-and-Reel Packaging and Pb-Free Reflow Profile

Packaging Information

Tape-and-reel packaging is used for SMT assembly. Labels include part number, lot number, IV, VF/IF, CCT/XY, Ra/SD/R9, quantity, date and code.

Reflow Profile

Pb-free SnAgCu assembly profile with 245-260 C peak temperature and 10-30 seconds within 5 C of peak.

Thermal Control

Ramp-up and ramp-down rates should be controlled according to the datasheet profile to protect LED package reliability.

Moisture Handling

After opening, soldering should be completed quickly. Remaining material should be sealed or stored under controlled humidity.

Engineering Review

Confirm solder pad design, thermal path, bin selection and application temperature before mass production.

FAQ

Common Buyer Questions

What is the rated current of this 2835 0.5W SMD LED?

The rated forward current is IF=150mA. Pulse forward current is 180mA max under 10kHz frequency and duty ratio <=10%.

What voltage range should engineers design for?

The datasheet lists forward voltage from 2.8V min to 3.4V max at IF=150mA for this 0.5W 2835 LED.

Which CCT and CRI options are available?

Available CCT options include 2700K, 3000K, 3500K, 4000K, 4500K, 5000K, 5700K and 6500K. CRI options include Ra70, Ra80 and Ra90.

What luminous flux can buyers expect?

Flux depends on CCT and CRI bin. The mass production list ranges from 55-60 lm for 2700K Ra90 to 80-85 lm for several Ra70 cool/neutral white bins at IF=150mA.

What soldering precautions should be followed?

The Pb-free reflow profile lists a 245-260 C peak temperature, 10-30 seconds within 5 C of peak, and total process time up to 480 seconds from 25 C to peak.

What packaging information is shown on the label?

The label includes part number, lot number, luminous flux bin, VF/IF, CCT/XY, Ra/SD/R9, quantity, date and code for production traceability.

How should opened packages be stored?

After opening, soldering should be completed as soon as possible, ideally within 12 hours. Remaining material should be sealed or stored at 5-40°C with humidity no more than 30%.

Is this 2835 LED suitable for flexible light panels?

The datasheet notes that the bracket is PCT material and may break when bent, so it is not suitable for flexible light panel type lamps.
